Telford 1800 x 450 Copper Grade 3 vented indirect twin coil hot water storage cylinder

• Need to allow 35mm of Lagging each side (+70mm diameter)

Vented indirect twin coil copper hot water storage cylinders feature two inter-wound coils at the base of the tank. Designed to be heated indirectly by a gas or oil-fired boiler suitable for both gravity and pumped heating systems. The water heated via the boiler is then passed through the coil which indirectly heats the domestic water inside the cylinder.

Features & Benefits

• Heated by a traditional boiler & immersion heater (not suitable for solar)
• 1” F BSP hot and cold connections
• Standard 1” M BSP coil suitable for both pumped and gravity coil
• Secondary Return connection available
• Highly efficient
• Ideal for retro-fit applications
• Fully insulated with 35mm foam to minimise any heat loss
• 1 x 2 1/4" immersion bosses
• Extra bosses available (including immersion bosses)
• Available in 80-440 litre capacities
• Attractive blue finish (white case finish also available)
• Easy to install
• Manufactured in accordance with BSI566:2002 (Part L)
• 10 year manufacturing warranty*
• Also available in Grade 2 & Grade 1 copper (call TDL for price)
• Renewable and bespoke options available

*Terms & Conditions apply
